Astralpool Smart+ 60 - SAFETY WARNINGS AND RECOMMENDATIONS

2
DESCRIPTION
MODEL
Smart+ 60 – Cod. 42350
Smart+PH 60 – Cod. 52569
Smart+ 100 – Cod. 42351
Smart+PH 100 – Cod. 52570
Smart+ 160 – Cod. 42352
Smart+PH 160 – Cod. 52571
Standard working voltage 230 V AC, 50
/
60 Hz.
Output (dc) 12 A 24 A 32 A
Production (g/h) 10 - 12 20 -24 25 - 32
Flow detector Gas detector + flow switch
Salinity range / Temperature 4 – 6 g./l.
/
+15
o
C – 40
o
C (59
o
F – 104
o
F)
Electrodes
SELF-CLEANING coated Titanium
Estimated lifetime: 4.000 – 7.000 hours of operation (depending on water quality)
Production control 0 – 100 % ( 11 production levels)
Cover control
Input for potential free contact
Programmable reduction of production from control panel when closed cover [10 ... 90%]
Polarity switch Programmable from control panel: 2/3 hours + test mode
External control
Two inputs for potential-free contacts for external flow detector and ORP/RESIDUAL CHLORINE
controller
Programmable contact logics from unit control panel
Salt level protection
A
utomatic production protection
DESCRIPTION
MODEL
Smart+PH 60 – Code 52569 Smart+PH 100 – Code 52570 Smart+PH 160 – Code 52571
Measurement range 0.0 – 9.9 (pH)
Control range 7.0 – 7.8 (pH)
Precision ± 0.1 pH
Calibration
A
utomatic with calibration solutions
Control outputs [pH] One output 230 V / 500 mA for dosage pump connection
pH sensor PPO body, range 0 – 14 (pH), solid electrolyte
Flow detector PPO Noryl GFN3 Casing / paddle, stainless steel 1,4571 shaft, EPDM O-ring
3. SAFETY WARNINGS AND RECOMMENDATIONS:_____________________________________________________________________
 The equipment should be assembled and handled by truly qualified people.
 Current electrical and accident prevention regulations should be followed.
 Under no circumstances will the manufacturer be held responsible for the assembly, installation or start-up, nor any handling or
fitting of components unless they are carried out on its premises.
 The AstralPool Chlore Salt Electrolysis Systems (42350, 42351, 42352, 52569, 52570, 52571) operate at 230VAC, 50/60 Hz. Do
not attempt to alter the system to operate at a different voltage.
 Check all the electrical connectors are well tightened to avoid false contacts and their consequent overheating.
 Before installing or replacing any component, disconnect the equipment from the mains, and use exclusively spare parts supplied
by AstralPool.
 Taking into account the fact that the equipment produces heat, it must be installed in places with sufficient ventilation. Fan
openings should be kept free of any element that could obstruct then. The equipment should not be installed near flammable
materials.
 The AstralPool Chlore Salt Electrolysis Systems (42350, 42351, 42352, 52569, 52570, 52571) have a protection degree of IP24.
They should never be installed in places susceptible to flooding.
 If the electrolysis equipment has no cover detection system, it is important to reduce its production to the minimum while the pool is
covered. Otherwise, an excess of chlorine could degrade the pool materials.
