Range hFE Test Current Test Voltage
PNP & NPN 0~1000 Ib≈2µA Vce≈1V
AC Current
Range Resolution Accuracy
600µA 0.1µA
±(1.5% of rdg +8dgts)
6000µA
1µA
60mA 10µA
600mA 100µA
10A 100mA ±(2.0% of rdg +10dgts)
Overload Protection:
● “mA” jack: F0.4A/600V fuse
● “10A” jack: F10A/600V fuse Max.
Input Current:
● “mA” jack: 400mA
● “10A” jack: 10A
(For measurements>5A: duration<10 seconds, interval >15 minutes)
Voltage Drop:
● 600µA, 60mA ranges: 60mV
● 6000µA, 600mA and 10A ranges: 600mV
Frequency Range: 40Hz ~ 400Hz
Resistance (Auto Ranging)
Range Resolution Accuracy
600Ω 0.1Ω
±(1.5% of rdg + 3dgts)
6KΩ 1Ω
60KΩ 10Ω
