ASUNA 7700 - Parts List; Tools & Hardware

NO.
DESCRIPTION
SPEC.
QTY
NO.
DESCRIPTION
SPEC.
QTY
1
Main Frame
1
25
Wire Plug
1
2
Base Frame
1
26
Left Cover
1
3
Handrail
1
27
Right Cover
1
4
Connecting Tube Seat
1
28
Magnetic Box
1
5
Rear Roller Cover
2
29
Screw
M8*70
2
6
Bolt Pinch Plate
1
30
Screw
M8*40
2
7
Sleeve
16*Φ12*40L
2
31
Screw
M8*55 thread length
25mm
2
8
Small Sleeve
Φ15*8.2*9.5L
4
32
Screw
M8*10
2
9
Front Roller Cover
2
33
Screw
M8*70 thread length
45mm
2
10
Front Axis Sleeve
2
34
Screw
M6*25
6
11
Front Roller
1
35
Screw
M8*30
2
12
Rear Roller
1
36
Screw
M8*15
4
13
Three-in-one Bolt
1
37
Screw
M6*15
8
14
Tension Switch
1
38
Screw
M5*30
2
15
Cylinder
1
39
Screw
M6*20
2
16
Nylon Sleeve
2
40
Screw
M12*55 thread length
30mm
2
17
Cushion
6
41
Washer
Φ8.5*Φ16*T1.5
14
18
Side Rail
2
42
Washer
Φ8.5*Φ16*T1.5
16
19
Running Board
1
43
Nut
M6
6
20
Running Belt
1
44
Nut
M8
4
21
Transportation Wheel
2
45
Tablet Bracket
1
22
Feet Cushion
2
46
Screw
M6*20
2
23
Transportation
Wheel Stopper
2
47
Allen Wrench
1
24
Flat Mat
4
Parts List
Tools & Hardware
