4-24 Chapter 4: Software support
*• Click Current to show the CO2 that has been reduced since
you click the Renew button .
*• Click Total to show the total CO2 that has been reduced
since you launched 6 Engine.
6 Engine main menu
Auto Mode
Runs calibration
Turbo Mode
High Performance Mode
Medium Power Saving Mode
Max. Power Saving Mode
Advanced settings for each mode (refer to the next page for further information)
Displays CPU Power and
Total CPU Energy Saving
*Shifts between
the display of Total
and Current CO2
reduced
Displays the
amount of CO2
reduced
Displays the following
message if no VGA power
saving engine is detected.
Exits the utility
Displays the system
properties of each
mode
Displays
current
mode
Lights up when power
saving engine is activated

Asus 4924238 - P6T LGA 1366 Motherboard Specifications

General

Model	P6T
Socket	LGA 1366
Chipset	Intel X58
Form Factor	ATX
Memory Slots	6
Maximum Memory	24GB
Supported Memory Types	DDR3
PCI Express 2.0 x16	3
PCI Express x4	1
PCI Slots	2
SATA 3Gb/s	6
SATA RAID	0, 1, 5, 10
USB Ports	12
Audio Channels	8
LAN Chipset	Marvell 88E8056
LAN	Gigabit Ethernet
PS/2	1
eSATA	1
Audio Ports	6
Dimensions (W x L)	30.5 cm x 24.4 cm
Audio	High Definition Audio
Max. LAN Speed	1000 Mbps
Power Pin	24-pin
