4-34 Chapter 4: BIOS setup
Duty Cycle Mode [90%]
Allows you to set the fan duty cycle. When the OPT_Fan1/2 Q-Fan Control item is
set to [Q-FAN], this item does not appear.
Conguraiton options: [70%] [80%] [90%] [100%]
TargetTemp Value [32]
Allows you to set the temperature at which the optional fan starts up. When the
OPT_Fan1/2 Q-Fan Control item is set to [DUTY CYCLE], this item does not
appear. Conguration options: [16] [24] [32] [40] [48] [56] [64] [72]
Power Fan Speed [xxxxRPM] or [Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the power
fan speed in rotations per minute (RPM). If the fan is not connected to the
motherboard, the eld shows N/A.
VCORE Voltage, FSB Termination Voltage, North Bridge Voltage,
DRAM Voltage, DRAM Reference Voltage, South Bridge Voltage, PLL
Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
