Asus Crosshair V Formula-Z User Manual

4-6
Chapter 4: Software support
Chapter 4
Fast Tuning: fast overclocking for the system
Extreme Tuning: extreme overclocking for the system
Using Fast Tuning
1. Click Auto Tuning tab > Fast.
2. Read the warning messages and click
Start to start the auto-overclocking
process.
TurboV automatically overclocks the
CPU, saves the BIOS settings, and
restarts the system.
•
•
Auto Tuning
ASUS TurboV EVO provides you with these two auto-tuning modes for the most exible auto-
tuning options.
• The overclocking result varies with the CPU model and the system conguration.
• We recommend that you set up a better thermal environment to prevent overheating
from damaging the motherboard.
3. After the system restarts, a message
appears indicating that auto-tuning is
successful. Click OK to exit.

Asus Crosshair V Formula-Z Specifications

General

Chipset	AMD 990FX
Socket	AM3+
Form Factor	ATX
Memory Slots	4
Maximum Memory	32GB
Memory Type	DDR3
Memory Standard	DDR3 2133(O.C.)/1866/1600/1333/1066
PCI Express x1	1
Max. LAN Speed	10/100/1000Mbps
Dimensions	30.5 cm x 24.4 cm
PCI Slots	1
SATA RAID	0, 1, 5, 10
Audio	SupremeFX III
LAN	Intel 82583V
USB 2.0	12 x USB 2.0
Power Pin	24-pin ATX
Multi-GPU Support	AMD Quad-GPU CrossFireX, NVIDIA Quad-GPU SLI
USB 3.0	4 (2 on back panel, 2 via header)
