Disassembly procedure
2 - 2
Battery Module
The illustration below shows how to remove the battery module.
Remove battery module
1．Slide the battery lock to open it
2．Slide the battery latch and hold the battery to remove it from system.
Memory Module
The illustration shows how to remove the memory module form the Eee PC 4G (701).
Removing Memory module
1. Remove 2 screws (M2*4) on the memory cover then remove it from the system.
BATTERY
MEMORY
MODULE
MEMORY
REMOVAL
1
