Asus Eee PC 4G - Memory Upgrade

Upgrade & replacement
4 - 2
Memory Upgrade
Upgrading Memory Module
Remove battery module
1．Slide the battery lock to open it
2．Slide the battery latch and hold the battery to remove it from system.
Removing Memory module
1. Remove 2 screws (M2*4) on the Memory cover then remove it from the system.
1
MEMORY
REMOVAL
MEMORY
