Assembly procedure
3 - 8
3.Install the mother board on bottom case, to install you should first install the top side,then softly
pry the two sides to the ports ends fit the bottom case well, finally press the bottom side to lock the
two latches.*make sure the antennas arrangeed through the hook at mother board, and all the cables
placed above the mother board.
4. Install the microphone , connect it with the mother board and then fix 1 piece of tape on the
cable.
