Hardware Technical Specification
5-39
Charge current (4S2P)
2.4A
2.46A 2.6A
Charge current (4S1P) 1.3A 1.4A 1.5A
Ripple & Noise 100mV
Efficiency 94%
7.4 Inverter Board
Inverter spec
Input Voltage: 9~11V
Output Current: 160mA(max)
Start Voltage: 12V(min)
Efficiency: 86%(max)
Brightness control duty:
Brightness adjust by input voltage: 0~3V
Support output short protection
Frequency: 25~35KHz
Pin no I/O Description
1 Input/ Output Return
2 Input/ Output High voltage
Brightness control duty: 0-100%
7.5 Adapter spec
7.5.1 Input
Input voltage: 100~240VAC,Full range
Input frequency: 50~60Hz
Input current: 680Ma(max)/100VAC
Inrush current: 60A(max)/100VAC, 120A(max)/240VAC
Efficiency: 85%(min)
7.5.2 Output
22W power output
Output Voltage/Current: 9.5V/2.315A
Ripple: 500mV
