ASUS ESC4000 G2 Series 5-29
5.4.13 OnboardLANConguration
Intel LAN Enable/Disable.
Onboard LAN Conguration
Intel W82574L OpROM1 [PXE]
Intel W82574L OpROM2 [PXE]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Intel W82574L OpROM1 [PXE]
Allows you to launch Intel W82574L OpROM1 boot mode.Conguration options:
[Disabled] [PXE] [iSCSI]
Intel W82574L OpROM2 [PXE]
llows you to launch Intel W82574L OpROM2 boot mode.Conguration options:
[Disabled] [PXE] [iSCSI]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

Asus ESC4000 G2 Specifications

General

Form Factor	2U Rackmount
Processor Support	Intel® Xeon® processor E5-2600 v2 series (up to 130W)
Processor	Intel® Xeon® processor E5-2600 v2 series
Chipset	Intel C602-A PCH
Memory Support	DDR3 1866/1600/1333/1066 MHz ECC Reg. DIMM Memory
Memory	DDR3 1866/1600/1333/1066 MHz ECC Reg. DIMM Memory
Memory Slots	16 x DIMM
Expansion Slots	1 x PCI-E x8 (Gen3 x8 Link)
Storage Bays	8 x 2.5" or 3.5" hot-swappable bays
Networking	Intel I350-AM2, 2 x Gigabit LAN
Operating System Support	Windows Server, Linux
Weight	25 kg
