Asus H110M-C D3 User Manual

vi
H110M-C D3 specifications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS H110M-C D3 motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7/ i5/ i3, Pentium
®
and Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
H110 Express Chipset
Memory
2 x DIMMs, max. 32 GB, DDR3 1600/1333 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please
refer to Memory QVL (Qualified Vendors List) for details.
** Due to Intel® chipset limitation, DDR3 1600 MHz and higher memory modules on XMP
mode will run at the maximum transfer rate of DDR3 1600 MHz.
*** To prevent system instability, either install DDR3L DIMMs or DDR3 DIMMs with voltage
lower than 1.5V.
**** Refer to www.asus.com for the Memory QVL(Qualified Vendors List).
Graphics
Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: DVI-D, RGB ports
- Supports DVI-D with max. resolution up to 1920 x 1200 @ 60Hz
- Supports RGB with max. resolution up to 1920 x 1200 @ 60Hz
Supports Quick Sync Video, Clear Video HD Technology
Maximum shared memory of 1024 MB
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (@ x16 mode)
2 x PCI Express 2.0 x1 slots
1 x PCI slot
Audio
Realtek ALC887 8-channel High Definition Audio CODEC
* Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
Storage
Intel
®
H110 Express Chipset
- 4 x Serial ATA 6.0 Gb/s connectors (gray)

Asus H110M-C D3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM, DDR3L-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-6xxx, i5-6xxx, i7-6xxx
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	16 Mbit
USB 2.0 connectors	1
Number of SATA III connectors	4
Number of Parallel ATA connectors	0
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H110
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Maximum graphics card memory	1024 MB
Parallel processing technology support	-

Weight and Dimensions

Depth	182 mm
Width	244 mm
