Asus H81T User Manual

vi
H81T specications summary
(continued on the next page)
CPU LGA1150 socket for Intel
®
4th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports 22nm CPU*
Supports Intel
®
Turbo Boost Technology 2.0**
* Up to 65W Thermal Design Power support for Intel
®
standard thin mini-ITX
heatsink. Up to 84W Thermal Design Power support for standard 1150/1155
heatsink.
** Intel
®
Turbo Boost Technology 2.0 support depends on the CPU type.
*** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory 2 x SO-DIMMs, max. 16GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
** When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics Integrated graphics processor
Multi-VGA output support: HDMI / DVI-I / LVDS
- Supports DVI-I with max. resolution of 1920 x 1200@60Hz
- Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
- Supports LVDS with max. resolution of 1920 x 1200 @60Hz
Maximum shared memory of 1024 MB
Expansion slots
1 x mini PCIe (half length)
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H81T motherboard
Cables 1 x Serial ATA 6.0 Gb/s cable, 1 x Serial ATA 3.0 Gb/s cable, 1 x SATA power cable
Accessories 2 x I/O Shield (1 x mini-ITX, 1 x thin mini-ITX)
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus H81T Specifications

General

Memory channels	Dual-channel
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
CPU fan connector	Yes
USB 2.0 connectors	3
Number of COM connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II, SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek 8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC887-VD
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	Not supported
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit
Cables included	SATA

Weight and Dimensions

Width	170 mm
