H81T specications summary
Internal connectors 2 x USB 2.0 2-port connectors support additional 4 USB 2.0 ports
1 x USB 2.0 1-port connectors support additional 1 USB 2.0 ports
1 x LVDS connector
1 x mini PCIe slot (half-length)
1 x SATA 6.0Gb/s connector
1 x SATA 3.0Gb/s connector
1 x mSATA connector
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x Clear CMOS jumper
1 x TPM header
1 x COM port header
1 x Chassis intrusion header
1 x SATA power connector
Connectors for AIO System
1 x 2-pin internal DC power connector
1 x Stereo speaker connector
1 x DMIC header
Connectors for Flat Panel Display
1 x Backlight inverter voltage selection header
1 x FPD brightness header
1 x Panel voltage selection header
1 x Panel off header
BIOS features 64 Mb Flash ROM, AMI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS 2.5,
ACPI v2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3
Manageability
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Support DVD Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
Specications are subject to change without notice.

Asus H81T Specifications

General

Memory channels	Dual-channel
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
CPU fan connector	Yes
USB 2.0 connectors	3
Number of COM connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II, SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek 8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC887-VD
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	Not supported
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit
Cables included	SATA

Weight and Dimensions

Width	170 mm
