Asus H971-PLUS - CPU Power States and PCH Configuration

CPU C-States [Auto]
This item allows you to set the power saving of the CPU states. Conguration options:
[Auto] [Disabled] [Enabled]
The following items appear only when you set the CPU C‑States to [Enabled].
Enhanced C1 state [Enabled]
This item allows your CPU to reduce power consumption when the system is in idle
mode. Conguration options: [Enabled] [Disabled]
CPU C3 Report [Enabled]
This item allows you to disable or enable the CPU C3 report to the operating
system. Conguration options: [Enabled] [Disabled]
CPU C6 Report [Enabled]
This item allows you to disable or enable the CPU C6 report to the operating
system. Conguration options: [Enabled] [Disabled]
C6 Latency [Short]
This item allows you to set the duration of C6 latency for C6 state. Conguration
options: [Short] [Long]
CPU C7 Report [CPU C7s]
This item allows you to disable or enable the CPU C7 report to the operating
system. Conguration options: [Disabled] [CPU C7] [CPU C7s]
C7 Latency [Long]
This item allows you to set the duration of C7 latency for C7 state. Conguration
options: [Short] [Long]
Package C State Support [Auto]
This item allows you to set the a C‑state support for the CPU package.
Conguration options: [Auto] [Enabled] [C0/C1] [C2] [C3] [C6] [CPU C7] [CPU C7s]
2.6.2 PCH Configuration
Intel Rapid Start Technology
Intel
®
Rapid Start Technology [Disabled]
Allows you to enable or disable Intel
®
Rapid Start Technology. Conguration options:
[Enabled] [Disabled]
The following items appear only when you set the Intel
®
Rapid Start Technology to
[Enabled].
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S3 mode.
Conguration options: [Enabled] [Disabled]
Entry After [0]
This item allows you to set the RTC wake‑up timer at S3 entry. The time ranges
from 0 minute (immediately) to 120 minutes.
ASUS H97I-PLUS 2‑31
