3. System memory
The motherboard comes with two Double Data Rate (DDR) Dual Inline
Memory Module (DIMM) sockets. These sockets support up to 2 GB system
memory using 184-pin unbuffered non-ECC PC3200/PC2700/PC2100/
PC1600 double-sided DDR DIMMs.
The following figure illustrates the location of the DDR DIMM sockets.
Memory configurationsMemory configurations
Memory configurationsMemory configurations
Memory configurations
You can install 128 MB, 256 MB, 512 MB, and 1 GB DDR DIMMs into the
DIMM sockets using the memory configurations in this section.
K8S-LA
K8S-LA 184-pin DDR DIMM sockets
80 Pins104 Pins
A DDR DIMM is keyed with a notch so that it fits in only one direction.
DO NOT force a DIMM into a socket to avoid damaging the DIMM.
