Set the ECC options
for cache and dram
scrubbing.
RS780D Conguration
NorthBridge2 Chipset Conguration
Internal Graphics Conguration
PCI Express Conguration
Primary Video Controller [GFX0-GPP-IGFX-PCI]
NB Power Management Features [Auto]
BIOS SETUP UTILITY
Advanced
Internal Graphics Conguration
This menu allows you to change the onboard graphics conguration settings. Select an item
then press <Enter> to display the sub-menu.
Advanced
Internal Graphics Conguration
Internal Graphics Mode [UMA+SIDEPORT]
UMA Frame Buffer Size [Auto]
SIDEPORT Clock Speed [667MHz]
SIDEPORT Voltage [Auto]
GFX Engine Clock Override [Disable]
UMA-SP Interleave Mode [Auto]
Surround View [Auto]
FB Location [Above 4G]
NB Azalia [Enable]
AMD 780 HD Audio [Enable]
Options
Disable
UMA
SIDEPORT
UMA+SIDEPORT
Internal Graphics Mode [UMA+SIDEPORT]
Conguration options: [Disable] [UMA] [SIDEPORT] [UMA+SIDEPORT]
UMA Frame Buffer Size [Auto]
Conguration options: [Auto] [32MB] [64MB] [128MB] [256MB] [512MB]
SIDEPORT Clock Speed [667MHz]
Conguration options: [533MHz] [667MHz] [700MHz] [715MHz] [730MHz] [745MHz]
[760MHz] [775MHz] [790MHz] [805MHz] [820MHz] [835MHz] [850MHz]
SIDEPORT Voltage [Auto]
Conguration options: [Auto] [1.50V] [1.60V]
GFX Engine Clock Override [Disable]
Allows you to enable or disable the GFX Engine Clock Override support.
Conguration options: [Disable] [Enable]
GFX Engine Clock [500]
This item appears only when you enable the GFX Engine Clock Override item.Use the <+>
and <-> keys to change the value or type the desired value using the numeric keypad. The
values range from 150 to 1500.
UMA-SP Interleave Mode [Auto]
Conguration options: [Auto] [Coarse] [Fine]
