DDR3-1600(O.C.) MHz capability
(continued on the next page)
Vendor Part No. Size
SS/
DS
Brand Chip NO.
Timing
DIMM
(BIOS)
Voltage
DIMM
Support
A* B*
G.SKILL F3-12800CL9D-2GBNQ 2048MB(Kit of 2) SS N/A Heat-Sink Package 9-9-9-24 1.5V~1.6V • •
G.SKILL F3-12800CL8T-6GBHK 2048MB DS N/A Heat-Sink Package 8-8-8-21 1.6~1.65 • •
G.SKILL F3-12800CL9T-6GBNQ 6144MB(Kit of 3) DS N/A Heat-Sink Package 9-9-9-24 1.5V~1.6V • •
Kingmax FLGD45F-B8KG9 1024MB SS Kingmax KFB8FNGXF-
ANX-12A
• •
Kingmax FLGD45F-B8MF7 MAEH(XMP) 1024MB SS N/A Heat-Sink Package 7 • •
Kingmax FLGE85F-B8KG9 2048MB DS Kingmax KFB8FNGXF-
ANX-12A
• •
Kingmax FLGE85F-B8MF7 MEEH(XMP) 2048MB DS N/A Heat-Sink Package 7 • •
Kingston KHX1600C9D3K2/4G 4096MB(kit of 2) DS N/A Heat-Sink Package 1.7-1.9V • •
Kingston KHX1600C9D3K3/6GX(XMP) 6144MB(Kit of 3) DS N/A Heat-Sink Package 1.65V • •
OCZ OCZ3G1600LV3GK 3072MB(Kit of 3) SS N/A Heat-Sink Package 8-8-8-24 1.65V • •
OCZ OCZ3G1600LV6GK 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 8-8-8-24 1.65V • •
Super
Talent
WA160UX6G9 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 9 • •
Transcend 8G DDR3 1600 DIMM CL11 8GB DS SEC 222
HYKO
6MD9639W - - •
Elixir M2X8G64CB8HB5N-DG(XMP) 8GB DS Elixir 1213 N2CB4G8BOBN-
DG
- - • •
DDR3-1333 MHz capability
Vendor Part No. Size
SS/
DS
Brand Chip NO.
Timing
DIMM
(BIOS)
Voltage
DIMM
Support
A* B*
A-Data AD31333001GOU 1024MB SS A-Data AD30908C8D-151C E0906 • •
A-Data AD31333G001GOU 3072MB(Kit of 3) SS N/A Heat-Sink Package 8-8-8-24 1.65-
1.85V
• •
A-Data AD31333002GOU 2048MB DS A-Data AD30908C8D-151C E0903 • •
A-Data AD31333G002GMU 2048MB DS N/A Heat-Sink Package 8-8-8-24 1.65-
1.85V
• •
Apacer 78.01GC6.9L0 1024MB SS Apacer AM5D5808AEWSBG0914E 9 • •
Apacer 78.A1GC6.9L1 2048MB DS Apacer AM5D5808AEWSBG0908D 9 • •
ASint SLB304G08-EDJ1B 8GB DS ASint SLB304G08-DJ1B - - • •
Corsair CM3X1024-1333C9DHX 1024MB SS N/A Heat-Sink Package 9-9-9-24 1.60V • •
Corsair CM3X1024-1333C9 1024MB SS N/A Heat-Sink Package • •
Corsair TR3X3G1333C9 G 3072MB(Kit of 3) SS N/A Heat-Sink Package 9-9-9-24 1.50V • •
Corsair TR3X3G1333C9 G 3072MB(Kit of 3) SS N/A Heat-Sink Package 9-9-9-24 1.50V • •
Corsair TR3X3G1333C9 3072MB(Kit of 3) SS N/A Heat-Sink Package 9 1.5V • •
Corsair CM3X1024-1333C9DHX 1024MB DS Corsair Heat-Sink Package • •
Corsair CM3X2048-1333C9DHX 2048MB DS N/A Heat-Sink Package • •
Corsair TW3X4G1333C9 G 4096MB(Kit of 2) DS N/A Heat-Sink Package 9-9-9-24 1.50V • •
Crucial CT12864BA1339.8FF 1024MB SS Micron 9FF22D9KPT 9 • •
Crucial CT12872BA1339.9FF 1024MB SS Micron 91F22D9KPT(ECC) 9 • •
Crucial BL12864TA1336.8SFB1 2048MB(Kit of 2) SS N/A Heat-Sink Package 6-6-6-20 1.8V • •
Crucial CT12864BA1339.8SFD 3072MB(Kit of 3) SS Micron 8XD22D9JNM 9 • •
Crucial CT25664BA1339.16FF 2048MB DS Micron 9KF27D9KPT 9 • •
Crucial CT25672BA1339.18FF 2048MB DS Micron 91F22D9KPT(ECC) 9 • •
Crucial BL25664ABA1336.16SFB1 4096MB(Kit of 2) DS N/A Heat-Sink Package 6-6-6-20 1.8V • •
Crucial BL25664BA1336.16SFB1 4096MB(Kit of 2) DS N/A Heat-Sink Package 6-6-6-20 1.8V • •
Crucial BL25664BN1337.16FF
(XMP)
6144MB(Kit of 3 ) DS N/A Heat-Sink Package 7-7-7-24 1.65V • •
Crucial CT25664BA1339.16SFD 6144MB(Kit of 3 ) DS Micron 8UD22D9JNM 9 •
ASUS M5A78L-M LX Series 1-13

Asus M5A78L-M LX V2 Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Supported memory module capacities	4GB
System bus rate	5.2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
Power fan connector	No
Number of SATA II connectors	6
Number of EATX power connectors	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	4
Audio chip	Realtek ALC887
Cooling type	Active
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB710
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
Cables included	SATA
Graphics card	Radeon HD 3000
DirectX version	10.0
Maximum resolution	2560 x 1440 pixels
Graphics card family	ATI
Parallel processing technology support	Hybrid CrossFireX
PCI Express slots version	2.0
Controller interface type	SB710
LAN controller	Realtek RTL8111E
Networking features	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	203 mm
Width	244 mm
