14 Chapter 1: Getting started
ENGLISH
ENGLISH
ENGLISH
ENGLISH
Audio 2.1, 4.1, 5.1, or 7.1-channel conguration
Port
Headset
2.1-channel
4.1-channel 5.1-channel 7.1-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
Side Speaker Out port (gray). This port connects to the side speakers in an
8-channel audio conguration.
Rear Speaker Out port (black). This port connects to the rear speakers in a 4, 6,
and 8-channel audio conguration.
Center/Subwoofer port (orange). This port connects to the center/subwoofer
speakers.
Microphone port (pink). This port connects to a microphone.
Line Out port (lime). This port connects to a headphone or speaker. In a 4.1, 5.2,
or 7.1-channel conguration, the function of this port becomes Front Speaker Out.
Line In port (light blue). This port connects to a tape, CD, DVD player, or other
audio sources.
Refer to the audio conguration table below for the function of the audio ports in a 2.1,
4.1, 5.1, or 7.1-channel conguration.
Activity/Link LED Speed LED
Status Description Status Description
OFF No link OFF 10Mbps connection
ORANGE Linked ORANGE 100Mbps connection
BLINKING Data activity GREEN 1Gbps connection
LAN port
SPEED
LED
ACT/LINK
LED
Expansion slot brackets. Remove the expansion slot bracket when installing an
expansion card
LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network
(LAN) through a network hub.
LAN port LED indications
