ASUS MAXIMUS VIII HERO
3-3
Chapter 3
3.2.1 EZ Mode
The EZ Mode provides you an overview of the basic system information, and allows you to
select the display language, system performance, mode and boot device priority. To access
the Advanced Mode, select Advanced Mode or press the <F7> hotkey for the advanced
BIOS settings.
The default screen for entering the BIOS setup program can be changed. Refer to the
Setup Mode item in section Boot menu for details.
The boot device options vary depending on the devices you installed to the system.
Selects the display language
of the BIOS setup program
Displays the CPU/motherboard temperature,
CPU voltage output, CPU/chassis/power fan
speed, and SATA information
Displays the system properties of the selected mode.
Click < or > to switch EZ System Tuning modes
Creates storage RAID and
configures system overclocking
Saves the changes
and resets the system
Click to display boot devices
Selects the boot device priority
Loads optimized default settings
Click to go to Advanced mode
Search on the FAQ
Displays the CPU Fan’s speed. Click
the button to manually tune the fans
Enables or disables the Intel
Rapid Storage Technology

Asus Maximus VIII Hero Specifications

General

Form Factor	ATX
Chipset	Intel Z170
Socket	LGA 1151
Memory Slots	4
Maximum Memory	64GB
Memory Type	DDR4
PCIe x16 Slots	3
PCIe x4 Slots	0
PCIe x1 Slots	3
SATA 6Gb/s Ports	6
M.2 Slots	1
USB 3.0 Ports	6
USB 2.0 Ports	6
Memory Speed	DDR4 2133/2400/2666/2800/3000/3200/3333/3400/3466 MHz (OC)
USB 3.1 Ports	1 x USB 3.1 Type-A, 1 x USB 3.1 Type-C
Audio	8-Channel High Definition Audio CODEC
LAN	Intel I219-V Gigabit LAN
RAID Support	0, 1, 5, 10
Multi-GPU Support	AMD 3-Way CrossFireX
