ASUS P4B-MX motherboard user guide 2-15
2.6.3 PCI slots
There are three 32-bit PCI slots in this motherboard. The slots support PCI
cards such as a LAN card, SCSI card, USB card, and other cards that
comply with PCI specifications.
The following figure shows a LAN card installed on a PCI slot.
2.6.4 AGP slot
This motherboard has an Accelerated Graphics Port (AGP) slot that
supports +1.5V AGP cards. When you buy an AGP card, make sure that
you ask for one with +1.5V specification.
Take note of the notches on the card golden fingers to ensure that they fit
the AGP slot on your motherboard. Below is an example of a +1.5V AGP
card.
Figure 2-19 Accelerated Graphics Port (AGP) Slot Location
Figure 2-18 Installed PCI Card
®
P4B-MX
P4B-MX Accelerated Graphics Port (AGP)
Keyed for 1.5V
