1-8 Chapter 1: Product introduction
1.5.3 Motherboard layout
24.5cm (9.6in)
24.5cm (9.6in
)
LGA775
PCIEX16
PCI1
PCI2
PCIEX4_1
EATXPWR
CD
KBPWR
CPU_FAN
Super I/O
DDR2 DIMM_A1 (64 bit,240-pin module)
DDR2 DIMM_A2 (64 bit,240-pin module)
DDR2 DIMM_B1 (64 bit,240-pin module)
DDR2 DIMM_B2 (64 bit,240-pin module)
FLOPPY
CHASSIS
PANEL
SATA2
TPM_SLOT
COM1
CHA_FAN2
CHA_FAN
Intel
ICH8DO
Intel
Q965
USB910
CLRTC
USB78USB56
PRI_EIDE
AAFP
AD1988
RTL8111B
JMicron
JMB363
CR2032 3V
Lithium Cell
CMOS Power
AUDIO
LAN_USB34
1394_USB12
PARALLE PORT
PS/2KBMS
T: Mouse
B: Keyboard
ATX12V
R
P5B-VM DO
SB_PWR
ESATA
VGA
SATA6
SATA4
SATA1
SATA_RAID1
SPDIF_OUT
ADHIE1394_2
SATA5
SATA3
PWR_FAN
TSB43AB22A
Refer to 1.10 Connectors for more information about rear panel connectors
and internal connectors.
