ASUS P5B-VM DO 1-29

2. Keyboard power (3-pin KBPWR)

This jumper allows you to enable or disable the keyboard wake-up feature.

Set this jumper to pins 2-3 (+5VSB) to wake up the computer when you press

a key on the keyboard (the default is the Space Bar). This feature requires

an ATX power supply that can supply at least 1A on the +5VSB lead, and a

corresponding setting in the BIOS.

P5B-VM DO

(Default)

+5V

+5VSB

KBPWR

P5B-VM DO Keyboard Power Setting
