Refer to the audio conguration table below for the function of the audio ports in
2, 4, 6, or 8-channel conguration.
Audio 2, 4, 6, or 8-channel conguration
Port Headset
2-channel
4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out
11. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports
are available for connecting USB 2.0 devices.
12. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports
are available for connecting USB 2.0 devices.
13. VGA port. This port is for a VGA monitor or other VGA-compatible devices.
14. External SATA port. This port connects to an external Serial ATA hard disk
drive. To congure a RAID 0, a RAID 1, or a JBOD set, install and external
Serial ATA hard disk drive and an internal Serial ATA hard disk drive to the
SATA connector labeled SATA_RAID or SATA_RAID1.
• Before creating a RAID set using Serial ATA hard disks, make sure that you
have connected the Serial ATA signal cable and installed Serial ATA hard
disk drives; otherwise, you cannot enter the JMicron RAID utility and SATA
BIOS setup during POST.
• If you intend to create a RAID conguration using this connector, set the
JMicron SATA Controller Mode
item in the BIOS to [RAID]. See section
“2.4.6 Onboard Device Conguration” for details.
The external SATA port supports external Serial ATA 3.0 Gb/s devices. Longer
cables support higher power requirements to deliver signal up to two meters
away, and enables improved hot-swap function.
• DO NOT insert a different connector to this port.
• DO NOT unplug the external Serial ATA box when a RAID 0 or JBOD is congured.
15. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.
