5-30 Chapter 5: RAID conguration
5.3 Intel
®
Matrix Storage Manager Option
ROM Utility
The Intel
®
Matrix Storage Manager Option ROM utility allows you to create RAID 0,
RAID 1, RAID 10 (RAID 10), and RAID 5 set(s) from Serial ATA hard disk drives that
are connected to the Serial ATA connectors supported by the Southbridge.
To enter the Intel
®
Application Accelerator RAID Option ROM utility:
1. Install all the Serial ATA hard disk drives.
2. Turn on the system.
3. During POST, press <Ctrl> + <I> to display the utility main menu.
Intel(R)MatrixStorageManagerOptionROMv5.0.0.1032ICH7RwRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
  4.Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes:
Nonedened.
Physical Disks:
PortDriveModelSerial#SizeType/Status(VolID)
0 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
1 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
2 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
3 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
[↑↓]-Select [ESC]-Exit[ENTER]-SelectMenu
The navigation keys at the bottom of the screen allow you to move through the
menus and select the menu options.
The RAID BIOS setup screens shown in this section are for reference only and
may not exactly match the items on your screen.
