Asus P5LD2-VM SE User Manual

1-21-2
1-21-2
1-2
Chapter 1: Product introductionChapter 1: Product introduction
Chapter 1: Product introductionChapter 1: Product introduction
Chapter 1: Product introduction
1.1 Welcome!
Thank you for buying an ASUSThank you for buying an ASUS
Thank you for buying an ASUSThank you for buying an ASUS
Thank you for buying an ASUS
®®
®®
®
P5LD2-VM SE motherboard! P5LD2-VM SE motherboard!
P5LD2-VM SE motherboard! P5LD2-VM SE motherboard!
P5LD2-VM SE motherboard!
The motherboard delivers a host of new features and latest technologies,
making it another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it,
check the items in your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
MotherboardMotherboard
MotherboardMotherboard
Motherboard ASUS P5LD2-VM SE motherboard
CablesCables
CablesCables
Cables 1 x Serial ATA signal cables
1 x Ultra DMA 133 cable
1 x Floppy disk drive cable
AccessoriesAccessories
AccessoriesAccessories
Accessories I/O shield
Application CDsApplication CDs
Application CDsApplication CDs
Application CDs ASUS motherboard support CD
DocumentationDocumentation
DocumentationDocumentation
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.
1.3 Special features
1.3.11.3.1
1.3.11.3.1
1.3.1
Product highlightsProduct highlights
Product highlightsProduct highlights
Product highlights
Latest processor technology Latest processor technology
Latest processor technology Latest processor technology
Latest processor technology
The motherboard comes with a 775-pin surface mount Land Grid Array
(LGA) socket designed for the Intel
®
Pentium
®
D, Intel
®
Pentium
®
4 or Intel
®
Celeron
®
processor in the 775-land package. The motherboard supports
the Intel
®
Pentium
®
4 or Intel
®
Pentium
®
D processor with 800/533 MHz
Front Side Bus (FSB). The motherboard also supports the Intel
®
Hyper-Threading Technology and is fully compatible with Intel
®
05B/05A/
06B processors. See page 1-9 for details.
IntelIntel
IntelIntel
Intel
®
Dual-Core Technology CPU support Dual-Core Technology CPU support
Dual-Core Technology CPU support Dual-Core Technology CPU support
Dual-Core Technology CPU support
The motherboard supports dual-core processors containing two physical
CPU cores with dedicated L2 caches to meet demands for more powerful
processing. See page 1-9 for details.

Asus P5LD2-VM SE Specifications

General

ECC	No
Number of memory slots	2
Maximum internal memory	2 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Maximum number of SMP processors	1
S/PDIF out connector	Yes
Number of SATA connectors	4
Special features	ASUS CrashFree BIOS 2 ASUS C.P.R. ASUS Q-Fan ASUS EZ Flash ASUS MyLogo
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Controller interface type	Serial ATA 300/150
Controller 2nd interface type	UltraDMA 100/66/33
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC882
Audio output channels	7.1 channels
Motherboard form factor	ATX
Bundled software	Drivers ASUS PC Probe II ASUS Update Anti-Virus software
Graphics card	GMA 950
Networking features	Gigabit Ethernet
BIOS memory size	32 Mbit

Weight and Dimensions

Width	245 mm
