Page #71 background imageLoading...
Page #71 background image
ASUS P5LD2-VMASUS P5LD2-VM
ASUS P5LD2-VMASUS P5LD2-VM
ASUS P5LD2-VM
2-272-27
2-272-27
2-27
ITE8211F Controller [Enabled]ITE8211F Controller [Enabled]
ITE8211F Controller [Enabled]ITE8211F Controller [Enabled]
ITE8211F Controller [Enabled]
Enables or disables the onboard ITE
®
8211F IDE controller.
Configuration options: [Enabled] [Disabled]
Detecting Device Time [Quick Mode]
Sets the ITE8211F detecting device time. If the devices installed on
the ITE IDE connector cannot be detected, set this item to Standard
Mode to enable complete detecting process. This item appears only
when the ITE8211F Controller is Enabled.
Configuration options: [Standard Mode] [Quick Mode]
Serial Port1 Address [3F8/IRQ4]Serial Port1 Address [3F8/IRQ4]
Serial Port1 Address [3F8/IRQ4]Serial Port1 Address [3F8/IRQ4]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4]
[2E8/IRQ3]
Parallel Port Address [378]Parallel Port Address [378]
Parallel Port Address [378]Parallel Port Address [378]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [ECP]Parallel Port Mode [ECP]
Parallel Port Mode [ECP]Parallel Port Mode [ECP]
Parallel Port Mode [ECP]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [Bi-directional] [EPP] [ECP]
ECP Mode DMA Channel [DMA3]ECP Mode DMA Channel [DMA3]
ECP Mode DMA Channel [DMA3]ECP Mode DMA Channel [DMA3]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode is set to [ECP]. This item
allows you to set the Parallel Port ECP DMA.
Configuration options: [DMA0] [DMA1] [DMA3]
EPP Version [1.9]EPP Version [1.9]
EPP Version [1.9]EPP Version [1.9]
EPP Version [1.9]
Allows selection of the Parallel Port EPP version. This item appears
only when the
Parallel Port ModeParallel Port Mode
Parallel Port ModeParallel Port Mode
Parallel Port Mode is set to
EPPEPP
EPPEPP
EPP.
Configuration options: [1.9] [1.7]
Parallel Port IRQ [IRQ7]
Configuration options: [IRQ5] [IRQ7]
