2-4 Chapter 2: Hardware information
2.2.4 Layout contents
Slots Page
1. DDR2 DIMM slots
2-13
2. PCI slot
2-21
3. PCI Express x 1 slots
2-21
4. PCI Express 2.0 x16 slots
2-21
Jumpers Page
1. Clear RTC RAM (3-pin CLRTC) 2-23
2. USB device wake-up (3-pin USBPW1-4, USBPW5-8) 2-24
3. Keyboard power (3-pin KBPWR) 2-24
Rear panel connectors Page
1. PS/2 mouse port (green)
2-25
2. Parellel port
2-25
3. IEEE 1394a port
2-25
4. LAN (RJ-45) port
2-25
5. Center/Subwoofer port (orange)
2-25
6. Rear Speaker Out port (black)
2-25
7. Line In port (light blue)
2-25
8. Line Out port (lime)
2-25
9. Microphone port (pink)
2-26
10. Side Speaker Out port (gray)
2-26
11. USB 2.0 ports 1 and 2
2-26
12. USB 2.0 ports 3 and 4
2-26
13. Serial port
2-26
14. Optical S/PDIF Out port
2-26
15. Coaxial S/PDIF Out port
2-26
16. PS/2 keyboard port (purple)
2-26
