ASUS P5Q-E 3-23
3.5 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other
system devices.
Take caution when changing the settings of the Advanced menu items. Incorrect
eld values can cause the system to malfunction.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
TPM Conguration
CPU Conguration
Chipset
Onboard Devices Conguration
USB Conguration
PCIPnP
BIOS SETUP UTILITY
Main Ai Tweaker Advanced Power Boot Tools Exit
Congure CPU.
TPM Conguration
TCG/TPM SUPPORT [NO]
Enable/Disable TPM
TCG (TPM 1.1/1.2)
supp in BIOS
BIOS SETUP UTILITY
Advanced
3.5.1 TPM Conguration
The items in this menu allow you to set the TPM (Trusted Platform Module)
features. Select an item then press <Enter> to display the conguration options.
The TPM Conguration item appears only when a TPM module is installed in
this motherboard.
TCG/TPM SUPPORT [YES]
Allows you to enable or disalbe TCG/TPM setting.
Conguration options: [YES] [NO]
The following items appear only when you set the TCG/TPM SUPPORT item to
[YES].
Execute TPM COMMAND [Last setting]
Allows you to enable or disable the TPM security chip.
Conguration options: [Last setting] [Disabled] [Enabled]

Asus P5Q-E Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Number of COM connectors	1
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
Audio chip	ADI AD2000B
Audio output channels	7.1 channels
Motherboard form factor	ATX
BIOS memory size	16 Mbit
RAID levels	0, 1, 10

Weight and Dimensions

Depth	244 mm
Width	305 mm
