Asus P5Q-E - Onboard Device Configuration

ASUS P5Q-E 3-27
3.5.4 Onboard Device Conguration
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
Onboard Device Conguration
High Denition Audio [Enabled]
Front Panel Type [HD Audio]
Marvell IDE [Enabled]
PCIE IDE Boot ROM [Enabled]
Marvell LAN1 [Enabled]
LAN Boot ROM [Disabled]
Marvell LAN2 [Enabled]
LAN Boot ROM [Disabled]
LSI Firewire 1394 [Enabled]
Serial Port1 Address [3F8/IRQ4]
Enable or Disable
High Denition Audio
Controller
High Denition Audio [Enabled]
Allows you to enable or disable the High Denition Audio Controller.
Conguration options: [Enabled] [Disabled]
Front Panel Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy
AC’97 or high-denition audio depending on the audio standard that the front
panel audio module supports. Conguration options: [AC97] [HD Audio]
Marvell IDE [Enabled]
Allows you to enable or disable the onboard Marvell IDE controller.
Conguration options: [Enabled] [Disabled]
PCIE IDE Boot ROM [Enabled]
This item appears only when you set the previous item to [Enabled].
Conguration options: [Disabled] [Enabled]
MarvelI LAN1/2 [Enabled]
Allows you to enable or disable the onboard Marvell LAN port1/2.
Conguration options: [Enabled] [Disabled]
LAN Boot ROM [Disabled]
This item appears only when you enable the previous item.
Conguration options: [Disabled] [Enabled]
Agere Firewire 1394 [Enabled]
Conguration options: [Enabled] [Disabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
BIOS SETUP UTILITY
Advanced
