Asus P8H77-I User Manual

1-18 Chapter 1: Product introduction
(continued on the next page)
DDR3-1333 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support (Optional)
1 DIMM 1 DIMM
A-DATA AM2U16BC2P1 2GB SS A-DATA
3CCD-1509A
EL1126T
- - • •
A-DATA AD31600E001GM(O)U3K 3GB(3 x 1GB) SS - - 8-8-8-24 1.65V-1.85V • •
A-DATA AX3U1600XB2G79-2X(XMP) 4GB(2 x 2GB) DS - - 7-9-7-21 1.55V-1.75V • •
A-DATA AM2U16BC4P2 4GB DS A-DATA
3CCD-1509
A EL1126T
- - • •
A-DATA AX3U1600GC4G9-2G(XMP) 8GB(2 x 4GB) DS - - 9-9-9-24 1.55V-1.75V • •
A-DATA AX3U1600XC4G79-2X(XMP) 8GB(2 x 4GB) DS - - 7-9-7-21 1.55V-1.75V • •
CORSAIR TR3X3G1600C8D(XMP) 3GB(3 x 1GB) SS - - 8-8-8-24 1.65V • •
CORSAIR CMD12GX3M6A1600C8(XMP) 12GB(6x2GB) DS - - 8-8-8-24 1.65V • •
CORSAIR CMP4GX3M2A1600C8(XMP) 4GB(2 x 2GB) DS - - 8-8-8-24 1.65V • •
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
A-DATA AD31333001GOU 1GB SS A-Data
AD30908C8D-
151C E0906
- - • •
A-DATA AD3U1333C2G9 2GB SS A-DATA 3CCD-1509HNA1126L - - • •
A-DATA AD63I1B0823EV 2GB SS A-Data 3CCA-1509A - - • •
A-DATA AM2U139C2P1 2GB SS ADATA 3CCD-1509A EL1127T - - • •
A-DATA AX3U1333C2G9-BP 2GB SS - - - - • •
A-DATA AD31333G001GOU
3GB(3
x 1GB)
SS - - 8-8-8-24 1.65-1.85V • •
A-DATA
AXDU1333GC
2G9-2G(XMP)
4GB(2
x 2GB)
SS - - 9-9-9-24
1.25V-1.35V
(low voltage)
• •
A-DATA AD31333G002GMU 2GB DS - - 8-8-8-24 1.65-1.85V • •
A-DATA AD63I1C1624EV 4GB DS A-Data 3CCA-1509A - - • •
A-DATA AM2U139C4P2 4GB DS ADATA 3CCD-1509A EL1127T - - • •
A-DATA SU3U1333W8G9-B 8GB DS ELPIDA J4208BASE-DJ-F - - • •
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808DEWSBG - - • •
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808FEQSBG 9 - • •
Apacer AU02GFA33C9NBGC 2GB DS Apacer AM5D5808APQSBG - - • •
Apacer 78.B1GDE.9L10C 4GB DS Apacer AM5D5908CEHSBG - - • •
CORSAIR TR3X3G1333C9 G
3GB(3
x 1GB)
SS - - 9-9-9-24 1.50V • •
CORSAIR TR3X6G1333C9 G
6GB(3x
2GB)
SS - - 9-9-9-24 1.50V • •
CORSAIR
CMD24GX3M6A
1333C9(XMP)
DS - - 9-9-9-24 1.60V • •
CORSAIR TW3X4G1333C9D G
4GB(2
x 2GB)
DS - - 9-9-9-24 1.50V • •
CORSAIR CM3X4GA1333C9N2 4GB DS CORSAIR
256MBDCJGELC
0401136
9-9-9-24 - • •
CORSAIR CMX4GX3M1A1333C9 4GB DS - - 9-9-9-24 1.50V • •
CORSAIR CMD8GX3M4A1333C7
8GB(4
x 2GB)
DS - - 7-7-7-20 1.60V • •
Crucial CT12864BA1339.8FF 1GB SS Micron 9FF22D9KPT 9 - • •
Crucial CT25664BA1339.16FF 2GB DS Micron 9KF27D9KPT 9 - • •
Crucial
BL25664BN
1337.16FF (XMP)
6GB(3
x 2GB)
DS - - 7-7-7-24 1.65V • •
ELPIDA EBJ10UE8EDF0-DJ-F 1GB SS ELPIDA J1108EDSE-DJ-F -
1.35V
(low voltage)
• •
ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F -
1.35V
(low voltage)
• •
G.SKILL
F3-10600CL8D
-2GBHK(XMP)
1GB SS G.SKILL - - - • •
G.SKILL F3-10600CL9D-2GBNQ
2GB(2
x 1GB)
SS - - 9-9-9-24 1.5V • •
G.SKILL
F3-10666CL7T
-3GBPK(XMP)
3GB(3
x 1GB)
SS - - 7-7-7-18 1.5~1.6V • •
G.SKILL
F3-10666CL8D-
4GBECO(XMP)
4GB(2
x 2GB)
DS - - 8-8-8-8-24 XMP 1.35V • •
G.SKILL
F3-10666CL7T
-6GBPK(XMP)
6GB(3
x 2GB)
DS - - 7-7-7-18 1.5~1.6V • •
G.SKILL
F3-10666CL7D
-8GBRH(XMP)
8GB(2
x 4GB)
DS - - 7-7-7-21 1.5V • •
GEIL GV32GB1333C9DC
2GB(2
x 1GB)
DS - - 9-9-9-24 1.5V • •
DDR3-1600 MHz capability

Asus P8H77-I Specifications

General

ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
Headphone outputs	3
USB 2.0 ports quantity	6
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	LucidLogix Virtu
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Bluetooth	No
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
