ASUS P8H77-I
1-19
DDR3-1333 MHz capability
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
GEIL GG34GB1333C9DC
4GB(2
x 2GB)
DS GEIL GL1L128M88BA12N 9-9-9-24
1.3V
(low voltage)
GEIL GV34GB1333C9DC
4GB(2
x 2GB)
DS - - 9-9-9-24 1.5V
GEIL GVP34GB1333C7DC
4GB(2
x 2GB)
DS - - 7-7-7-24 1.5V
Hynix HMT112U6TFR8A-H9 1GB SS Hynix H5TC1G83TFRH9A -
1.35V
(low voltage)
Hynix HMT325U6BFR8C-H9 2GB SS Hynix H5TQ2G83BFRH9C - -
Hynix HMT125U6TFR8A-H9 2GB DS Hynix H5TC1G83TFRH9A -
1.35V
(low voltage)
Hynix HMT351U6BFR8C-H9 4GB DS Hynix H5TQ2G83BFRH9C - -
KINGMAX FLFD45F-B8KL9 NAES 1GB SS KINGMAX KKB8FNWBFGNX-27A - -
KINGMAX FLFE85F-C8KF9 CAES 2GB SS KINGMAX KFC8FMFXF-DXX-15A - -
KINGMAX FLFE85F-C8KL9 NAES 2GB SS KINGMAX KFC8FNLXF-DXX-15A - -
KINGMAX FLFE85F-C8KM9 NAES 2GB SS KINGMAX KFC8FNMXF-BXX-15A - -
KINGMAX FLFE85F-B8KL9 NEES 2GB DS KINGMAX KKB8FNWBFGNX-26A - -
KINGMAX FLFF65F-C8KL9 NEES 4GB DS KINGMAX KFC8FNLXF-DXX-15A - -
KINGMAX FLFF65F-C8KM9 NEES 4GB DS KINGMAX KFC8FNMXF-BXX-15A - -
KINGSTON
KVR1333D3N
9/1G(low prole)
1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V
KINGSTON
KVR1333D3N
9/2G(low prole)
2GB SS Hynix H5TQ2G83AFRH9C 9 -
KINGSTON KVR1333D3S8N9/2G 2GB SS Micron IID77 D9LGK - 1.5V
KINGSTON
KVR1333D3S8N
9/2G-SP(low prole)
2GB SS ELPIDA J2108BCSE-DJ-F - 1.5V
KINGSTON
KVR1333D3N9/2G(low
prole)
2GB DS ELPIDA J1108BFBG-DJ-F 9 1.5V
KINGSTON KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V
KINGSTON KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V
KINGSTON
KVR1333D3N
9/2G-SP(low prole)
2GB DS KTC D1288JEMFNGD9U - 1.5V
KINGSTON
KVR1333D3N
9/2G-SP(low prole)
2GB DS KINGSTON D1288JPSFPGD9U - 1.5V
KINGSTON
KHX1333C7D3K
2/4GX(XMP)
4GB(2
x 2GB)
DS - - 7 1.65V
KINGSTON
KHX1333C9D3UK2/
4GX(XMP)
4GB(2
x 2GB)
DS - - 9 XMP 1.25V
KINGSTON
KVR1333D3N
9/4G(low prole)
4GB DS ELPIDA J2108BCSE-DJ-F 9 1.5V
KINGSTON
KVR1333D3
N9/4G(low prole)
4GB DS ELPIDA J2108BCSE-DJ-F - 1.5V
KINGSTON KVR1333D3N9/4G 4GB DS KTC D2568JENCNGD9U - 1.5V
KINGSTON KVR1333D3N9/4G 4GB DS Hynix H5TQ2G83AFR - -
KINGSTON
KVR1333D3N
9/4G-SP(low prole)
4GB DS KINGSTON D2568JENCPGD9U - 1.5V
Micron MT4JTF12864AZ-1G4D1 1GB SS Micron OJD12D9LGQ - -
Micron MT8JTF12864AZ-1G4F1 1GB SS Micron 9FF22D9KPT 9 -
Micron MT8JTF25664AZ-1G4D1 2GB SS Micron OJD12D9LGK - -
Micron MT8JTF25664AZ-1G4M1 2GB SS MICRON IJM22 D9PFJ - -
Micron MT16JTF25664AZ-1G4F1 2GB DS Micron 9KF27D9KPT 9 -
Micron MT16JTF51264AZ-1G4D1 4GB DS Micron OLD22D9LGK - -
NANYA NT4GC64B8HG0NF-CG 4GB DS NANYA NT5CB256M8GN-CG - -
PSC AL7F8G73F-DJ2 1GB SS PSC A3P1GF3FGF - -
PSC AL8F8G73F-DJ2 2GB DS PSC A3P1GF3FGF - -
SAMSUNG M378B2873FHS-CH9 1GB SS SAMSUNG K4B1G0846F - -
SAMSUNG M378B5773DH0-CH9 2GB SS SAMSUNG K4B2G0846D - -
SAMSUNG M378B5673FH0-CH9 2GB DS SAMSUNG K4B1G0846F - -
SAMSUNG M378B5273CH0-CH9 4GB DS SAMSUNG K4B2G0846C - -
SAMSUNG M378B1G73AH0-CH9 8GB DS SAMSUNG K4B4G0846A-HCH9 - -
Super Talent W1333UA1GH 1GB SS Hynix H5TQ1G83TFR 9 -
Super Talent W1333UX2G8(XMP)
2GB(2x
1GB)
SS - - 8 -
Super Talent W1333UB2GS 2GB DS SAMSUNG K4B1G0846F 9 -
Super Talent W1333UB4GS 4GB DS SAMSUNG K4B2G0846C - -
Super Talent W1333UX6GM
6GB(3x
2GB)
DS Micron 0BF27D9KPT 9-9-9-24 1.5V
Transcend JM1333KLN-2G 2GB SS Hynix H5TQ2G83BZRH9C - -
Transcend TS256MLK64V3U 2GB DS Micron 9GF27D9KPT - -
Century
PC3-10600 DDR3
-1333 9-9-9
1GB SS NANYA NT5CB128M8DN-CF - -
(continued on the next page)
