Asus P8H77-M User Manual

1-20 Chapter 1: Product introduction
DDR3-1600MHz capability
continued on the next page
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
KINGSTON KHX1600C9D3P1K2/8G 8GB(2 x 4GB) DS - - - 1.5V • • •
Super
Talent
WA160UX6G9 6GB(3 x 2GB) DS - - 9 - •
Transcend JM1600KLN-8GK 8GB(2 x 4GB) DS Transcend TK483PCW3 - - • • •
Asint SLZ3128M8-EGJ1D(XMP) 2GB DS Asint
3128M8-
GJ1D
9-9-9-24 1.6V • • •
Asint SLA302G08-EGG1C(XMP) 4GB DS Asint
302G08-
GG1C
- - • • •
Asint SLA302G08-EGJ1C(XMP) 4GB DS Asint
302G08-
GJ1C
- - • • •
Elixir M2P2G64CB8HC9N-DG(XMP) 2GB DS - - - - • • •
Kingtiger KTG2G1600PG3 2GB DS - - - -
Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 - • • •
Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5~1.6V • • •
PATRIOT PGS34G1600LLKA 4GB(2 x 2GB) DS - - 7-7-7-20 1.7V • • •
SanMax SMD-4G68HP-16KZ 4GB DS HYNIX
H5TQ2G83B
FR PBC
- - • • •
DDR3-1333MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
A-DATA AD31333001GOU 1GB SS A-Data
AD30908C8D-151C
E0906
- - • • •
A-DATA AD3U1333C2G9 2GB SS A-DATA
3CCD-
1509HNA1126L
- - • • •
A-DATA AD63I1B0823EV 2GB SS A-Data 3CCA-1509A - - • • •
A-DATA AM2U139C2P1 2GB SS ADATA
3CCD-1509A
EL1127T
- - • • •
A-DATA AX3U1333C2G9-BP 2GB SS - - - - • • •
A-DATA AD31333G001GOU 3GB(3 x 1GB) SS - - 8-8-8-24 1.65-1.85V •
A-DATA
AXDU1333GC2
G9-2G(XMP)
4GB(2 x 2GB) SS - - 9-9-9-24
1.25V-1.35V
(low voltage)
• • •
A-DATA AD31333G002GMU 2GB DS - - 8-8-8-24 1.65-1.85V • •
A-DATA AD63I1C1624EV 4GB DS A-Data 3CCA-1509A - - • • •
A-DATA AM2U139C4P2 4GB DS ADATA
3CCD-1509A
EL1127T
- - • • •
A-DATA SU3U1333W8G9-B 8GB DS ELPIDA J4208BASE-DJ-F - - • • •
Apacer 78.A1GC6.9L1 2GB DS Apacer
AM5D5808D
EWSBG
- - • • •
Apacer 78.A1GC6.9L1 2GB DS Apacer
AM5D5808F
EQSBG
9 - • • •
Apacer AU02GFA33C9NBGC 2GB DS Apacer
AM5D5808
APQSBG
- - • • •
Apacer 78.B1GDE.9L10C 4GB DS Apacer
AM5D5908
CEHSBG
- - • • •
CORSAIR CM3X1024-1333C9 1GB SS - - 9-9-9-24 1.60V • • •
CORSAIR TR3X3G1333C9 G 3GB(3 x 1GB) SS - - 9-9-9-24 1.50V • • •
CORSAIR TR3X6G1333C9 G 6GB(3 x 2GB) SS - - 9-9-9-24 1.50V • •
CORSAIR
CMD24GX3M6A
1333C9(XMP)
24GB
(6 x 4GB)
DS - - 9-9-9-24 1.60V • • •
CORSAIR TW3X4G1333C9D G 4GB(2 x 2GB) DS - - 9-9-9-24 1.50V • • •
CORSAIR CM3X4GA1333C9N2 4GB DS CORSAIR
256MBDCJGE
LC0401136
9-9-9-24 - • • •
CORSAIR CMX4GX3M1A1333C9 4GB DS - - 9-9-9-24 1.50V • • •
CORSAIR CMD8GX3M4A1333C7 8GB(4 x 2GB) DS - - 7-7-7-20 1.60V • • •
Crucial CT12864BA1339.8FF 1GB SS Micron 9FF22D9KPT 9 - • • •
Crucial CT25664BA1339.16FF 2GB DS Micron 9KF27D9KPT 9 - • • •
Crucial
BL25664BN1337.16FF
(XMP)
6GB(3 x 2GB) DS - - 7-7-7-24 1.65V • • •

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
