Asus P8H77-M User Manual

ASUS P8H77-M 1-21
DDR3-1333MHz capability
continued on the next page
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
ELPIDA EBJ10UE8EDF0-DJ-F 1GB SS ELPIDA J1108EDSE-DJ-F -
1.35V
(low voltage)
• • •
ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F -
1.35V
(low voltage)
• •
G.SKILL
F3-10600CL8D-2GBHK
(XMP)
1GB SS G.SKILL - - - • • •
G.SKILL F3-10600CL9D-2GBNQ 2GB(2 x 1GB) SS - - 9-9-9-24 1.5V • • •
G.SKILL
F3-10666CL7T-3GBPK
(XMP)
3GB(3 x 1GB) SS - - 7-7-7-18 1.5~1.6V • • •
G.SKILL
F3-10666CL8D-
4GBECO(XMP)
4GB(2 x 2GB) DS - - 8-8-8-8-24 XMP 1.35V • • •
G.SKILL
F3-10666CL7T-6GBPK
(XMP)
6GB(3 x 2GB) DS - - 7-7-7-18 1.5~1.6V • •
G.SKILL
F3-10666CL7D-8GBRH
(XMP)
8GB(2 x 4GB) DS - - 7-7-7-21 1.5V • • •
GEIL GV32GB1333C9DC 2GB(2 x 1GB) DS - - 9-9-9-24 1.5V • • •
GEIL GG34GB1333C9DC 4GB(2 x 2GB) DS GEIL GL1L128M88BA12N 9-9-9-24
1.3V
(low voltage)
• • •
GEIL GV34GB1333C9DC 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V • • •
GEIL GVP34GB1333C7DC 4GB(2 x 2GB) DS - - 7-7-7-24 1.5V • • •
Hynix HMT112U6TFR8A-H9 1GB SS Hynix H5TC1G83TFRH9A -
1.35V
(low voltage)
• • •
Hynix HMT325U6BFR8C-H9 2GB SS Hynix H5TQ2G83BFRH9C - - • • •
Hynix HMT125U6TFR8A-H9 2GB DS Hynix H5TC1G83TFRH9A -
1.35V
(low voltage)
• • •
Hynix HMT351U6BFR8C-H9 4GB DS Hynix H5TQ2G83BFRH9C - - • • •
KINGMAX FLFD45F-B8KL9 NAES 1GB SS KINGMAX
KKB8FNWBFGNX-
27A
- - • • •
KINGMAX FLFE85F-C8KF9 CAES 2GB SS KINGMAX
KFC8FMFXF-
DXX-15A
- - • • •
KINGMAX FLFE85F-C8KL9 NAES 2GB SS KINGMAX
KFC8FNLXF-
DXX-15A
- - • • •
KINGMAX FLFE85F-C8KM9 NAES 2GB SS KINGMAX
KFC8FNMXF-
BXX-15A
- - • • •
KINGMAX FLFE85F-B8KL9 NEES 2GB DS KINGMAX
KKB8FNWBFGNX-
26A
- - • • •
KINGMAX FLFF65F-C8KL9 NEES 4GB DS KINGMAX
KFC8FNLXF-
DXX-15A
- - • • •
KINGMAX FLFF65F-C8KM9 NEES 4GB DS KINGMAX
KFC8FNMXF-
BXX-15A
- - • • •
KINGSTON
KVR1333D3N9/1G
(low prole)
1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V • • •
KINGSTON
KVR1333D3N9/2G
(low prole)
2GB SS Hynix H5TQ2G83AFRH9C 9 - • •
KINGSTON KVR1333D3S8N9/2G 2GB SS Micron IID77 D9LGK - 1.5V • • •
KINGSTON
KVR1333D3S8N
9/2G-SP(low prole)
2GB SS ELPIDA J2108BCSE-DJ-F - 1.5V • • •
KINGSTON
KVR1333D3N9/2G
(low prole)
2GB DS ELPIDA J1108BFBG-DJ-F 9 1.5V • • •
KINGSTON KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V • • •
KINGSTON KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V • • •
KINGSTON
KVR1333D3N9/2G-SP
(low prole)
2GB DS KTC D1288JEMFNGD9U - 1.5V • • •
KINGSTON
KVR1333D3N9/2G-SP
(low prole)
2GB DS KINGSTON D1288JPSFPGD9U - 1.5V • • •
KINGSTON
KHX1333C7D3K2/4GX
(XMP)
4GB(2 x 2GB) DS - - 7 1.65V • • •
KINGSTON
KHX1333C9D3UK2/4GX
(XMP)
4GB(2 x 2GB) DS - - 9 XMP 1.25V • • •
KINGSTON
KVR1333D3N9/4G
(low prole)
4GB DS ELPIDA J2108BCSE-DJ-F 9 1.5V • • •
KINGSTON
KVR1333D3N9/4G
(low prole)
4GB DS ELPIDA J2108BCSE-DJ-F - 1.5V • • •
KINGSTON KVR1333D3N9/4G 4GB DS KTC D2568JENCNGD9U - 1.5V • • •
KINGSTON KVR1333D3N9/4G 4GB DS Hynix H5TQ2G83AFR - - • • •

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
