Asus P8H77-V LE User Manual

x
ASUS Exclusive
Overclocking Features
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.005V increment
- vCCSA: 191-step system agent voltage control
- vDRAM Bus: 191-step Memory voltage control
- vPCH: 191-step Chipset voltage control
- iGPU: 127-step iGPU voltage control
- vCPU_PLL: 1-step CPU & PCH PLL voltage control
SFS (Stepless Frequency Selection)
- BCLK/PCIE frequency tuning from 80MHz up to 300MHz at
1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
Back Panel I/O Ports 1 x PS/2 Keyboard/Mouse COMBO port
1 x HDMI Output port
1 x DVI Output port
1 x RGB Output port
1 x LAN (RJ45) port
2 x USB 3.0 ports
4 x USB 2.0/1.1 ports
1 x Optical S/PDIF Out
3-jack 8-channel Audio jack(s)
Internal I/O Connector 3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1
ports
1 x USB 3.0/2.0 connectors support additional 2 USB 3.0/2.0
ports
2 x SATA 6Gb/s connectors (gray)
4 x SATA 3Gb/s connectors (blue)
1 x 4-pin CPU Fan connector
1 x 3-pin Chassis Fan connector
1 x Front Panel Audio connector
1 x System Panel connector
1 x 24-pin ATX Power connector
1 x 8-pin ATX 12V Power connector
1 x S/PDIF Out connector
1 x MemOK! Button
1 x Clear CMOS jumper
1 x COM connector
BIOS 64 Mb Flash ROM, UEFI BIOS, PnP, DMI2.0, WfM2.0, SM
BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2,
ASUS CrashFree BIOS 3, F12 PrintScreen function, F3 Shortcut
function, and ASUS DRAM SPD (Serial Presence Detect)
memory information
Manageability
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Accessories 2 x Serial ATA 6.0Gb/s cables
1 x I/O Shield
1 x User’s manual
1 x Support DVD
P8H77-V LE specications summary
(continued on the next page)

Asus P8H77-V LE Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-2xxx, i3-3xxx, i5-2xxx, i5-3xxx, i7-2xxx, i7-3xxx
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	4.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	218 mm
Width	305 mm
