Asus P8H77-V LE User Manual

viii
P8H77-V LE specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3rd/2nd Generation Core™ i7/ i5/ i3/
Pentium
®
/ Celeron
®
Processors
Supports 22nm and 32nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
*The Turbo Boost Thchnology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H77 Express Chipset
Memory 4 x DIMM, maximum 32GB, DDR3 1866(O.C.)*/1600/1333/1066 MHz,
non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to the CPU behavior, DDR3 1866 MHz memory module will run
at DDR3 1800 MHz frequency as default.
** Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Some hyper DIMMs only support one DIMM per
channel. Please refer to Memory QVL for details.
*** Refer to www.asus.com or this User Manual for the Memory
QVL(Qualied Vendors List).
**** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less than
3GB. We recommend a maximum of 3GB system memory if you are
using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot [bue] (at x16 mode)*
1 x PCI Express 2.0 x16 slot [black] (at x4 mode, compatible with PCIe
x1, x2 and x4 devices)
2 x PCI Express 2.0 x1 slot
3 x PCI slots
* PCIe 3.0 speed is supported by Intel
®
3rd generation Core™
processors.
Graphics Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI, DVI and RGB port
- Supports HDMI with max. resolution up to 1920 x 1200 @60Hz
- Supports DVI with max. resolution up to 1920 x 1200 @60Hz
- Supports RGB with max. resolution 2048 x 1536@75Hz
- Supports Intel
®
InTru™ 3D/Insider™/Quick Sync Video/Clear Video
HD Technology/HD Graphics
- Maximum shared Memory of 1696 MB
Multi-GPU
support
Supports ATI
®
Quad-GPU CrossFireX™ Technology
Supports Lucidlogix
®
Virtu MVP™ Technology*
* LucidLogix
®
Virtu MVP™ supports Windows
®
7 operating systems.
Storage Intel
®
H77 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (gray)
- 4 x Serial ATA 3.0 Gb/s connectors (blue)
- Intel Rapid Storage Technology supports RAID 0, 1, 5 and 10
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology, Intel
®
Smart Connect Technology*
* Supports on Intel
®
Core™ processor family with Windows
®
7
operating systems.

Asus P8H77-V LE Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-2xxx, i3-3xxx, i5-2xxx, i5-3xxx, i7-2xxx, i7-3xxx
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	4.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	218 mm
Width	305 mm
