2-16 ASUS P8H77-V LE
iGPU Load-line Calibration [Auto]
Load-line Calibration is dened by Intel VRM specications and affects iGPU voltage. The
iGPU working voltage will decrease proportionally to the integrated graphics loading. Higher
load-line calibration would get higher voltage and better overclocking performance, but
increase the CPU and VRM thermal. This item allows you to adjust the voltage range from
the following percentages to boost the system performance: 0% (Regular), 50% (High) and
100% (Extreme). Conguration options: [Auto] [Regular] [High] [Extreme]
iGPU Current Capability [100%]
Allows you to set the iGPU Current Capability. Conguration options: [100%] [110%] [120%]
Do not remove the thermal module while changing the DIGI+ VRM related parrameters .
The thermal conditions should be monitored.
Some of the following items are adjusted by typing the desired values using the numeric
keypad and press the <Enter> key. You can also use the <+> and <-> keys to adjust the
value. To restore the default setting, type [auto] using the keyboard and press the <Enter>
key.
2.4.9 CPU Voltage [Offset Mode]
[Manual Mode] Allows you to set a xed CPU voltage.
[Offset Mode] Allows you to set the Offset voltage.
CPU Offset Mode Sign [+]
This item appears only when you set the CPU Voltage item to [Offset Mode].
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Offset Voltage [Auto]
This item appears only when you set the CPU Voltage item to [Offset Mode] and
allows you to set the Offset voltage. The values range from 0.005V to 0.635V with a
0.005V interval.
CPU Manual Voltage [Auto]
This item appears only when you set the CPU Voltage item to [Manual Mode] and allows you
to set a xed CPU voltage. The values range from 0.800V to 1.990V with a 0.005V interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage
may damage the CPU permanently, and setting a low voltage may make the system
unstable.
2.4.10 iGPU Voltage [Offset Mode]
[Offset Mode] To offset the voltage by a positive or negative value.
[Manual Mode] Allows you to set a xed iGPU voltage.
iGPU Offset Mode Sign [+]
This item appears only when you set the iGPU Voltage item to [Offset Mode].
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
