Asus P8H77-V LE User Manual

Chapter 2: BIOS information 2-17
iGPU Offset Voltage [Auto]
This item appears only when you set the iGPU Voltage item to [Offset Mode] and
allows you to set the iGPU Offset voltage. The values range from 0.005V to 0.635V
with a 0.005V interval.
iGPU Manual Voltage [Auto]
This item appears only when you set the iGPU Voltage item to [Manual Mode] and allows
you to set a xed iGPU voltage. Use the <+> and <-> keys to adjust the value. The values
range from 0.800V to 1.990V with a 0.005V interval.
2.4.11 DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.185V to 2.135V with a 0.005V
interval.
According to Intel CPU spec, DIMMs with voltage requirement over 1.65V may damage
the CPU permanently. We recommend you install the DIMMs with the voltage requirement
below 1.65V.
2.4.12 VCCSA Voltage [Auto]
Allows you to set the VCCSA voltage. The values range from 0.610V to 1.560V with a 0.005V
interval.
2.4.13 PCH Voltage [Auto]
Allows you to set the PCH voltage. The values range from 0.7350V to 1.6850V with a 0.005V
interval.
• The values of the CPU Offset Voltage, CPU Manual Voltage, iGPU Offset Voltage,
iGPU Manual Voltage, DRAM Voltage, VCCSA Voltage, and PCH Voltage are labeled
in different color, indicating the risk levels of high voltage settings.
• The system may need better cooling system to work stably under high voltage settings.
2.4.14 CPU PLL Voltage [Auto]
Allows you to set the CPU PLL voltage. Use <+> and <-> keys to adjust the value.
Conguration options: [Auto] [+0.10V].

Asus P8H77-V LE Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-2xxx, i3-3xxx, i5-2xxx, i5-3xxx, i7-2xxx, i7-3xxx
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	4.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	218 mm
Width	305 mm
