Asus P9X79-E WS - Layout Contents

2.2.2 Layout contents
Connectors/Jumpers/Switches/Slots Page
1. ATX Power connectors (24-pin EATXPWR, 8-pin EATX12V, 6-pin
EATX12V_1)
2-35
2. DDR3 DIMM slots
2-7
3.
LGA2011 CPU Socket 2-6
4.
CPU, CPU OPT, Chassis fan connectors (4-pin CPU_FAN,
4-pin CHA_OPT, 4-pin CHA_FAN1/2/3/4)
2-32
5. Reset switch
2-11
6. Power-on switch
2-11
7. ASUS Dr._POWER switch
2-14
8.
MemOK! switch 2-13
9. EPU Switch
2-12
10. USB 3.0 connector (20-1 pin USB3_34)
2-29
11. Intel
®
X79 Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_1/2 [gray])
2-26
12. Intel
®
X79 Serial ATA 3.0 Gb/s connectors
(7-pin SATA3G_3–6 [blue])
2-27
13. Marvell
®
Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_E1/E2/E3/E4 [gray])
2-28
14. Q-Code LED
2-16
15. System panel connector (20-8 pin PANEL)
2-36
16. USB 2.0 connectors (Type A: USB13; 10-1 pin USB1112)
2-30
17. TPM connector (20-1 pin TPM)
2-34
18. IEEE 1394a port connector (10-1 pin IE1394_1)
2-31
19.
Serial port connector (10-1 pin COM1) 2-34
20.
Clear RTC RAM (3-pin CLRTC) 2-24
21. Chassis Fan control setting (3-pin CHAFAN_SEL)
2-25
22. TPU switch
2-12
23. Front panel audio connector (10-1 pin AAFP)
2-33
24. Digital audio connector (4-1 pin SPDIF_OUT)
2-31
ASUS P9X79-E WS
2-5
