2-2 Chapter 2: Setup
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm).
2.3 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• You can adjust the monitor’s angle from +23˚ to -5˚, and it allows 30˚ swivel
adjustment from either left or right. You can also adjust the monitor’s height
within +/- 130 mm.
30°
0°
30°
130mm
+23° ~ -5°
(Tilt) (Swivel) (Height adjustment)
