Asus PA32UCX Series User Manual

1-2 Chapter 1: Product introduction
1.3 Monitor introduction
 
6
2
7
4
5
3
1
Menu
Close
Input Select
QuickFit
Brightness
HDR
1. Menu (5-way) button:
• Press this button to enter the OSD menu.
• Enacts the selected OSD menu items.
• Increases/Decreases values or moves your selection up/down/left/right.
2. Close button:
• Exits the OSD menu.
• Toggles the Key Lock function between on and off with a long press for
5 seconds.
3. Input select button:
• Selects an available input source.
Press button (Input Select button) to display HDMI-1, HDMI-2, HDMI-
3, Thunderbolt, DisplayPort signals after you connect HDMI/DisplayPort/
Thunderbolt cable with the monitor.
4. QuickFit button:
• This is a hotkey to activate the QuickFit function designed for alignment.
• The QuickFit function contains 5 types of alignment patterns. (Please refer
to 1.3.3 QuickFit Function).
5. Shortcut
• Default: Brightness hotkey

Asus PA32UCX Series Specifications

General

Screen Size	32 inches
Resolution	3840 x 2160 (4K UHD)
Panel Type	IPS
Brightness	1000 cd/m² (peak)
Aspect Ratio	16:9
Refresh Rate	60 Hz
Contrast Ratio	1000:1
Viewing Angle	178°(H)/178°(V)
Color Depth	10-bit (1.07 billion colors)
Local Dimming Zones	1152
VESA Mount	100 x 100 mm
HDR	Dolby Vision, HDR10, HLG
Color Gamut	99.5% Adobe RGB, 100% sRGB
Ports	HDMI 2.0, DisplayPort 1.2, Thunderbolt 3, USB 3.1
Response Time	5ms (Gray to Gray)
Speakers	Yes
USB Hub	Yes
Adjustability	Height, Tilt, Swivel, Pivot
Weight	13.6 kg (with stand)
