Asus PA34VC User Manual

1-2 Chapter 1: Product introduction
1.3 Monitor introduction
 
Menu
Close
Input Select
PIP/PBP
Brightness
HDR
6
2
7
4
5
3
1
1. Menu (5-way) button:
• Enters the OSD menu.
• Enacts the selected OSD menu items.
• Increases/Decreases values or moves your selection up/down/left/right.
2. Close button:
• Exits the OSD menu.
• Toggles the Key Lock function between on and off with a long press for
5 seconds.
3. Input select button:
• Selects an available input source.
Press button (Input Select button) to display HDMI-1, HDMI-2,
Thunderbolt, DisplayPort signals after you connect HDMI/DisplayPort/
Thunderbolt cable with the monitor. Thunderbolt is the default setting. Select
DisplayPort if you want to connect a DisplayPort device.
4. PIP/PBP button:
• This is a hotkey to enter the PIP/PBP setting menu.
5. Shortcut 1
• Default: Brightness hotkey
