ASUS Q87T
1-19
Q87T
Q87T RTC battery header
PIN 1
VBAT GND
BATT_CON
11. RTC Battery header (2-pin BATT_CON)
This connector is for the lithium CMOS battery.
12. Embedded DisplayPort (40-pin eDP)
The connector is for an internal embedded DisplayPort connection.
Q87T
Q87T embedded Display Port
eDP(Back)
PIN 1
13. LVDS connector (40-pin LVDS)
This connector is for an LCD monitor that supports Low-voltage Differential Signaling
(LVDS) interface.
Q87T
Q87T LVDS connector
LVDS
PIN 1
