x
(continued on the next page)
LAN
Aquantia AQC-108 5G LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
Multi-GPU support
Supports NVIDIA
®
2-Way/Quad-GPU SLI™ Technology
Supports AMD
®
4-Way/Quad-GPU CrossFireX™ Technology
Audio
ROG SupremeFX S1220A Codec
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-channel audio.
USB
Intel
®
Z370 Express Chipset:
- 8 x USB 3.1 Gen 1 ports ( 2 ports at mid-board [grey])
- 6 x USB 2.0 ports (6 ports at mid-board [black])*
ASMedia
®
USB 3.1 controller
- 2 x USB 3.1 Gen 2 ports ( 1 Type-A [red] and 1 Type-C™ [black]
at back panel)
* 2 x USB 2.0 ports at mid-board share with ROG extension (ROG_EXT)
port.
Back I/O Ports
1 x Clear CMOS Button
1 x BIOS Flashback Button
1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x HDMI 1.4b
1 x DisplayPort 1.2
6 x USB 3.1 Gen1 ports [blue]
1 x Anti-surge 5G LAN (RJ45) port
1 x Anti-surge LAN (RJ45) port
2 x USB 3.1 Gen 2 ports (1 x Type-A [red] and 1 x Type-C [black])
1 x Optical S/PDIF out
5 x Gold-plated audio jacks
ROG MAXIMUS X APEX specifications summary
