Internal I/O Ports
1 x USB 3.1 Gen 1 header support additional 2 x USB 3.1 Gen 1
ports
3 x USB 2.0 headers support additional 6 x USB 2.0 ports
[one connector via ROG_EXT header]
4 x SATA 6Gb/s ports
1 x DIMM.2 slot
1 x ROG extension (ROG_EXT) header
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
3 x 4-Pin Chassis fan connectors
1 x 4-Pin Water_pump+ connector
1 x 4-Pin AIO_Pump connector
2 x Thermal sensor connectors
3 x 4-Pin Full speed fan connectors (FS_FAN)
1 x 24-Pin EATX power connector
2 x 8-Pin EATX 12V power connectors
1 x W_IN header
1 x W_OUT header
1 x W_FLOW header
1 x Start button
1 x Reset button
1 x LN2 mode jumper
1 x MemOK! Button
4 x Aura RGB headers
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x BIOS switch button
1 x Slow mode Switch
1 x PCIe x16 Lane Switch
9 x ProbeIt measurement points
1 x EZ Plug connector
1 x Pause Switch
3 x LED ON/OFF headers (M.2_LIGHT, LIGHT_BAR1, LIGHT_
BAR2)
1 x System panel connector
ROG MAXIMUS X APEX specifications summary
