1-8
Chapter 1: Product Introduction
Chapter 1
Hyper M.2 X16 series card configuration
Slot
PCIe bifurcation settings in PCIe x16 slots with different Ryzen™
CPUs
3
rd
Gen AMD Ryzen™ Processors (Support PCIe Gen 4 SSDs)
Supported SSDs
PCIEX16_1
4 or 2
PCIEX16_2
0 or 2
• Hyper M.2 X16 series card is purchased separately.
• When using 3
rd
Gen AMD Ryzen™ Processors and a Hyper M.2 X16 series card with
4 M.2 SSDs, if you wish to connect a display, we suggest installing a VGA card to
PCIe X16_2, which will run at x4.
• Set PCIEX16_1 to [PCIe RAID Mode] under BIOS settings to enable the Hyper M.2
X16 series card.
