Chapter 2: Basic Installation
Chapter 2
2.1.4 M.2 installation
• The M.2 rubber pad is
optional for when installing
a single sided M.2 storage
device. Ensure to install the
bundled M.2 rubber pad
before installing your single
sided M.2 storage device.
• DO NOT install the bundled
M.2 rubber pads when
installing a double-sided
M.2 storage device. The
rubber pad installed by
default is compatible with
double sided M.2 storage
devices.
1
1
2
1
1
2
OPTIONAL
3
5
5
4
4
To Next Page
