Chapter 2: Basic Installation
Chapter 2
2.1.8 Front I/O connector
To install front panel connector
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector
USB 3.2 Gen2
To install USB 3.2 Gen2 connector
This connector will only fit in one
orientation. Push the connector until
it clicks into place.
To install system speaker connector
