ROG STRIX B550-E GAMING
1-19
Chapter 1
16. S/PDIF Out header
The S/PDIF Out header allows you to connect the Sony/Philips Digital Interface (S/
PDIF) Out module.
SPDIF_OUT
+5V SPDIFOUT GND
The S/PDIF module is purchased separately.
17. Speaker header
The 4-pin header is for the chassis-mounted system warning speaker. The speaker
allows you to hear system beeps and warnings.
+5V GND GND Speaker Out
SPEAKER
PIN 1
