Asus ROG STRIX XG43VQ User Manual

2-3ASUS LCD Monitor XG Series
2.3 Detaching the arm/stand (for VESA wall
mount)
• Avoid damaging the monitor surface. While detaching the
monitor stand, always keep the monitor inside its EPS
packaging.
The detachable stand of this monitor is specially designed for VESA wall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the monitor
facedown on its EPS packaging.
2. Remove the covers on where the monitor and the arm meet.
3. Remove the four (4) screws securing the arm to the rear of the
monitor.
4. Detach the stand (arm and base) from the monitor.
• Use only the UL Listed Wall Mount Bracket with minimum
weight/load 28.8 kg (Screw size: M4 x 10 mm).

Asus ROG STRIX XG43VQ Specifications

General

Panel Size	43.4” W (110.23 cm)
Max. Resolution	3840 x 1200
Brightness (Typ.)	450 nits (typical)
Intrinsic Contrast Ratio (Typ.)	3000:1
Viewing Angle (CR>10)	178°(V) /178°(H)
Display Colors	1.07B (8bit+2FRC)
PBP	Yes
Response Time	4 ms (G To G )
Sound from HDMI	Yes
Earphone	Yes
Speaker	5 W x 2
HDMI input	HDMI2.0 x 2
DisplayPort input	Yes
USB3.0 Port	Upstream x1, Downstream x2 (USB port without power charger when upstream no link)
Power On Consumption	< 47 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	Adapter 20Vdc, 7.5A
Chassis Colors	Black
Tilt	-5° ~ 20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension with stand (WxHxD)	1057.12 x 517.46 x 309.03 mm
Phys. Dimension without stand (WxHxD)	1057.12 x 361.26 x 158.66 mm
Box Dimension (WxHxD)	1152 x 456 x 370 mm
Net Weight with Stand (Esti.)	12.0 kg
Net Weight without Stand (Esti.)	8.3kg
Gross Weight (Esti.)	TBD kg
